• Mist maker outside case.
• Fixed hole.
• Positive power supply.
• Negative power supply.
• Water level sensor.
• Indicate light.
• Mist plate Metal pressure ring.
• Sealing ring.
About
• Mist maker outside case.
• Fixed hole.
• Positive power supply.
• Negative power supply.
• Water level sensor.
• Indicate light.
• Mist plate Metal pressure ring.
• Sealing ring.
Testing Item | Testing Condition Minimum | Minimum | Normal | Maximum | Unit |
---|---|---|---|---|---|
Voltage | water shortage | 40 | 45 | 55 | V |
Voltage | spray state | 40 | 45 | 50 | V |
Electric Current | spray state | 4600 | 4800 | 5000 | MA |
Standby Current | water shortage | 10 | 20 | 30 | MA |
Mist Capacity | Clean water | 4500 | 5000 | 6000 | ML/H |
water temp | 5 | 30 | 50 | °C | |
Optimum working level | Clean water | 25 | 35 | 45 | MM |
Atomizer open water | Clean water | 12 | 20 | 25 | MM |
Atomizer open water | pure water | 12 | 20 | 26 | MM |
Atomizer off water | Clean water | 5 | 14 | 22 | mm |
Atomizer off water | pure water | 5 | 15 | 23 | mm |
Water Conductivity | water 25°C | 8 | 160 | 250 | US/CM |
Temperature control switch | Start control temp | 50 | 55 | 60 | °C |
Temperature control switch | Recover temp | 35 | 40 | 45 | °C |
Service life | Clean water | >3000 | / | / | Hours |
Power cord length | 1400 | 1500 | 1600 | MM |
