2.0-2.5T Electric Pallet Truck(AC)

About

Advantage.

• Configuration and performance;

• Electronic power steering system light and low noise;

• Drive unit floating bodies with patent design;

• AC driving system no carbon brush maintenance free;

• USA CURTIS controller;

• Electromagnetic regenerative braking system;

• Automatic lifting limit proximity switch long life;

SAFETY.

• Curve automatic deceleration devices safer;

• Stepless speed control system safe and quiet;

• Controller with multiple automatic protection;

• Emergency reversing device/Emergency brake switch;


Technical specifications

ModelAEJE/ERE 220-AEJE/ERE 225
FEATURELoad capacitykg2000/2500
FEATURELoad centermm600
FEATUREWheel basemm1480
FEATUREOperating typeWalkle/Stand on
WHEELWheel typePU
WHEELwheel quantity Driving  wheel/balance wheel bearing wheelmm1/2/4
WHEELDriving wheel sizemmC248x75
WHEELBalance wheel sizemmC80x80(Double wheels)
WHEELBearing wheel sizemmC115x55
DEMENSIONMin.fork lowerd heightmm85
DEMENSIONMax.fork lifting heightmm205
DEMENSIONMax.lifing heightmm120
DEMENSIONOverall fork heightmm540/600/685/1070
DEMENSIONFork lengthmm1150/1200
DEMENSIONFork widthmm185
DEMENSIONFork thicknessmm55
DEMENSIONOverall lengthmm1900/2305
DEMENSIONOverall widthmm735
DEMENSIONOverall height(with handle)mm1455
DEMENSIONOverall height(without handle)mm900
DEMENSIONmin.turning radiusmm1735/2140
DEMENSION(800x1200,1200)min.aisle width for pallets 800x1200mm2060/2451
DEMENSION(1000x1200,1200)min.aisle width for pallets 1000x1200mm2090/2468
PERFORMANCETravel speed,laden/unladenkm/h5.7/6
PERFORMANCELift speed,laden unladenmm/s30/45
PERFORMANCETravel speed laden/unladenmm/s45/30
PERFORMANCEGradeability laden/unladen%6/8
ELECTRIC CONFIGURATIONDrive motorkwAC 1.5/2.0
ELECTRIC CONFIGURATIONLift motorkwDC 2.0
ELECTRIC CONFIGURATIONSteering motorkwDC 0.15
ELECTRIC CONFIGURATIONBattery voltage/capacityV/Ah24/210-240
ELECTRIC CONFIGURATIONBrakeElectromagnetic/ regenerative
ELECTRIC CONFIGURATIONControllerCURTIS(USA)
WEIGHTBattery weightkg200-230
WEIGHTService weight with batterykg790-820
